300M Enterprise Ceiling-Mounted Wireless AP
·Support 1*100M LAN, 1*100M WAN, built-in 2.4G antenna
·Fat and fit in one, support seamless roaming and automatically selects channels
·Powerful radio frequency design, safe and stable, wide coverage
·Support DC 9~48V power input or WAN port PoE power receiving
·Support -40℃~65℃ operating temperature
300M Enterprise Ceiling-Mounted Wireless AP
·Support 1*100M LAN, 1*100M WAN, built-in 2.4G antenna
·Fat and fit in one, support seamless roaming and automatically selects channels
·Powerful radio frequency design, safe and stable, wide coverage
·Support DC 9~48V power input or WAN port PoE power receiving
·Support -40℃~65℃ operating temperature
Product Description
CIAP6300-T adopts IEEE802.11n standard wireless access technology and advanced MIMO technology, Qualcomm QCA9531 chip, built-in high-gain antenna, speed up to 300M, with a capacity of less than 50 people, effective distance of more than 800m, and is compatible with IEEE802.11n (2.4G) protocol; PoE power supply technology, Support unified management by AC controller, can manage 300 APs at the same time, and is suitable for wireless coverage in enterprises, schools, hotels and other places. At the same time, the unique watchdog technology makes the AP work more stable and ensures the normal operation of the wireless network for a long time.
Product Features
l 11N high power, also support 2.4G coverage
l Support independent use and AC centralized management
l Support multiple SSIDs, support Chinese SSIDs
l Support multiple VLANs, SSID can be bound to VLAN
l Extremely large capacity, up to 50 users
Software | |
Network Management | Configuration method: WEB System: Immortal WEB Uboot; Openwr, QXWLAN Capacity: up to 50 users |
RF Parameters | |
CPU | Qualcomm-Atheros QCA9531 |
Wireless speed | 300Mbps |
Modulation | DSSS/CCK BPSK/QPSK OFDM BPSK/QPSK/16-QAM/64-QAM |
DDR | 64M |
FLASH | 16M |
RF Interface | U.FL*2 |
Wireless Protocol | 802.11g/n |
Wireless Frequency | 2.4G |
Power | 26dBm@2.4G |
Frequency | 2412MHz-2482MHz |
Acceptance Sensitivity | Maximum -96dBm |
Channel Bandwidth | 20M/40MHz (adjustable) |
Effective Distance | More than 800 meters |
Interface | |
Interface | 2*10M/100M RJ45 |
Power Supply | |
Power Input | DC 9~48V (DC round head); 48V standard PoE power supply (WAN port) |
Average Power Consumption | 5W |
Physical Characteristics | |
Dimensions | 204×20(mm)(Ф×H) |
Weight | About 0.3kg |
Working Environment | |
Operating Temp | -40℃~65℃ |
Storage Temp | -40℃~85℃ |
Relative Humidity | 5%~95% (non-condensing) |
Industry Standard | |
Certification | CE, FC, RoHS |
400mW ESD MIMO AP | ||||||||||
TX SPECIFICATIONS | ||||||||||
DataRate | TX Power(per chain) | TX Power(2 chains) | Tolerance | |||||||
802.11G | 6-24Mbps | 23dBm | 26dBm | ±2dB | ||||||
36Mbps | 23dBm | 26dBm | ±2dB | |||||||
48Mbps | 22dBm | 25dBm | ±2dB | |||||||
54Mbps | 21dBm | 24dBm | ±2dB | |||||||
DataRate | TX Power TX Power | Tolerance | DataRate | TX Power TX Power | Tolerance | |||||
(1 chain) | (2 chains) | (1 chain) | (2 chains) | |||||||
2.4GHz 11n HT 20 | MCS 0/8 | 23dBm | 26dBm | ±2dB | 2.4GHz 11n HT 40 | MCS 0/8 | 23dBm | 26dBm | ±2dB | |
MCS 1/9 | 23dBm | 26dBm | ±2dB | MCS 1/9 | 23dBm | 26dBm | ±2dB | |||
MCS 2/10 | 23dBm | 26dBm | ±2dB | MCS 2/10 | 23dBm | 26dBm | ±2dB | |||
MCS 3/11 | 22dBm | 25dBm | ±2dB | MCS 3/11 | 22dBm | 25dBm | ±2dB | |||
MCS 4/12 | 22dBm | 25dBm | ±2dB | MCS 4/12 | 22dBm | 25dBm | ±2dB | |||
MCS 5/13 | 22dBm | 25dBm | ±2dB | MCS 5/13 | 22dBm | 25dBm | ±2dB | |||
MCS 6/14 | 22dBm | 25dBm | ±2dB | MCS 6/14 | 22dBm | 25dBm | ±2dB | |||
MCS 7/15 | 21dBm | 24dBm | ±2dB | MCS 7/15 | 21dBm | 24dBm | ±2dB | |||
RX SPECIFICATIONS | ||||||||||
DataRate | Sensitivity | Tolerance | DataRate | Sensitivity | Tolerance | |||||
(2 chains) | (2 chains) | |||||||||
802.11G | 6M | -96dBm | ±2dB | 802.11G | 24M | -89dBm | ±2dB | |||
9M | -96dBm | ±2dB | 36M | -86dBm | ±2dB | |||||
12M | -95dBm | ±2dB | 48M | -82dBm | ±2dB | |||||
18M | -93dBm | ±2dB | 54M | -79dBm | ±2dB | |||||
2.4GHz 11n HT 20 | MCS0 | -95dBm | ±2dB | 2.4GHz 11n HT 40 | MCS0 | -92dBm | ±2dB | |||
MCS1 | -93dBm | ±2dB | MCS1 | -90dBm | ±2dB | |||||
MCS2 | -90dBm | ±2dB | MCS2 | -87dBm | ±2dB | |||||
MCS3 | -89dBm | ±2dB | MCS3 | -84dBm | ±2dB | |||||
MCS4 | -85dBm | ±2dB | MCS4 | -81dBm | ±2dB | |||||
MCS5 | -81dBm | ±2dB | MCS5 | -77dBm | ±2dB | |||||
MCS6 | -79dBm | ±2dB | MCS6 | -76dBm | ±2dB | |||||
MCS7 | -75dBm | ±2dB | MCS7 | -74dBm | ±2dB |
Name | Version | Resources |
CIAP6300-T Datasheet | V1.0 | Download |
Standard Model | Description |
CIAP6300-T | 300M enterprise ceiling-mounted wireless AP |
